Lifeline system BR 8 Standard

8 mm Safety system

Product description

The lifeline system BR 8 Standard using a 8 mm stainless steel cable is intended as the baseline configuration for a lifeline system comprising two cable clamps type B.

direct request

Product data

  • Certification:DIN EN 795:2012
  • Stainless steel cable:⌀ 8 mm
  • Number of users:max. 4 persons
  • Number of users per glider:max. 1 person
  • Support spacing:max. 15 m
  • Application:Horizontally
Product variantsDownloads & Service

Variants

Key data at a glance

All product variants

VersionArticle numberCable clamp
BR 8E7169972 pcs.

Everything at a glance

Assembly documentation via app

Go to the appContact us
